Kiwi back again with a thread for discussing actuators to move your waifu! Part Three!
Let's start with a quick introduction to common actuators!
1. DC motors, these use brushes to switch the ferrous core electromagnets on a rotor to rotate its magnetic field relative to surrounding magnets! They're one of the cheapest options with an average efficiency range of 30 to 90%. Larger DC motors and motors with higher turn counts are more efficient.
1.5 Coreless DC motors, by removing ferrous materials, losses from hysteresis are almost eliminated, dramatically increasing efficiency to nearly 90% even in small motors. Eliminating the ferrous materials reduces flux focusing, resulting in weaker fields and higher speeds.
2. Brushless DC motors (BLDC), these use a controller to switch the electromagnets on a stator to rotate the magnets of a rotor! Without brushes, they have the potential to be more efficient with higher power density compared to DC motors. Their efficiency and behavior vary depending on the algorithm and sensors used to control them. Coreless brushless motors exist but are rare and only used for very niche applications.
3. AC motors, a wide and incredibly varied category. They all rely on AC’s frequency to control them. With single phase AC motors relying on shaded poles, capacitors, or some other method to induce a rotating magnetic field. 3 phase AC motors naturally have a rotating field which usually gives them higher efficiency and power density. Notably, most AC motors are brushless. The most commonly used brushed AC motor is the universal motor, which is
4. Stepper motors, brushless motors with ferrous teeth to focus magnetic flux. This allows for incredible control (stepping) at the cost of greater mass, subsequently giving them higher rotary inertia. Usually 50 to 80% efficient depending on control algorithm/speed/and quality of the stepper. Due to their increasing mass production (& ubiquitous low cost controllers), they have appeal as a lower cost alternative to BLDC motors if one carefully designs around them.
5. Coiled Nylon Actuators! These things have an efficiency rating so low it's best to just say they aren't efficient. (0.01% typical, 2% achieved under extremely specific conditions in a lab.) Though they are exciting due to their incredible low cost of fabrication, they’re far too slow and the energy requirements are nonsensical.
https://youtu.be/S4-3_DnKE9E
https://youtu.be/wltLEzQnznM
6. Hydraulics! These rely on the distribution of pressure in a working liquid to move things like pistons. Though popular in large scale industry, their ability to be used in waifu's has yet to be proven. (Boston Dynamics Atlas runs on hydraulics but it's a power guzzler and heavy) Efficiency varies wildly depending on implementation. They would work great for a giantess!
7. Pneumatics, hydraulics lighter sister! This time the fluid is air! This has the advantage in weight. They aren't capable of the same power loads hydraulics are but, who wants their waifu to bench press a car?
(Too loud and inefficient for mobile robotics.)
8. Wax motors, hydraulic systems where the working fluid is expanding melted (commonly paraffin) wax! Cheap, low power, and produce incredible forces! Too bad they're slow and hard to control.
9. Explosion! Yes, you can move things through explosions! Gas engines work through explosions! Artificial muscles can be made by exploding a hydrogen and oxygen mixture in a piston, then using hydrolysis to turn the water back into hydrogen and oxygen. None of this is efficient or practical but it's vital we keep our minds open! Though there are more actuators, most are derivatives or use these examples to work. Things like pulleys need an actuator to move them. Now, let's share, learn, and get our waifu moving!
